7F2C50-BAAACAAAAAAABSKA1 Endress+Hauser F Prowirl F 200 7F2C50 DN50

Brand Name : E+H

Model Number : 7F2C50-BAAACAAAAAAABSKA1

Certification : ce

Place of Origin : Germany

MOQ : 1pcs

Price : USD1785/PCS

Payment Terms : T/T

Delivery Time : 5-8works

Packaging Details : carton

Warranty : 1 Year

Level input : 1x sensor FDU9x/8x

Origina : Germany

Additional inputs : None (none)

Electrode Material : 316L, Hastelloy C, Platinum

name : 7FC50

Contact Now

7F2C50-BAAACAAAAAAABSKA1 Endress+Hauser F Prowirl F 200 7F2C50 DN50

Approval:BA

ATEX II1G Ex ia IIC

Output; Input:A

4-20mA HART

Display; Operation:A

W/o; via communication

Housing:C

GT20 dual compartment,alu,coated,compact

Cable, Remote Version:A

Not used

Electrical Connection:A

Gland M20

Sensor Version; DSC-Sensor; Meas. Tube:AA

Volume; 316L; 316L -40...+260oC/-40...+500oF

DSC-Sensor Seal:A

Graphite, -200oC… +400oC, -328oF…752oF

Pressure component:A

Not used

Process Connection:ABS

Cl.300 RF Sch.40, flange ASME B16.5

Calibration Flow:K

0.75% volume 3-point

Device Model:A1

Details:

Curr. output 1: Volume flow

Select medium: Steam

Current span: 4...20 mA NAMUR

4 mA value: 0 m3/h

20 mA value: 821.00000 m3/h

Failsafe mode current output: Max.

Operating temperature: 20.00000 °C

Damping output 1: 2.00000 s

Totalizer 1: null

Unit: m3

Failure mode: Stop

Totalizer 2: null

Unit: kg

Failure mode: Stop

Totalizer 3: null

Unit: Nm3

Failure mode: Sto

Net weight: 12.741 Kilogram

SPK: DBI

HS-Code: 90268020

Country of origin: FR

Country of dispatch: FR

7F2C50-BAAACAAAAAAABSKA1 Endress+Hauser F Prowirl F 200 7F2C50 DN50
